G I Air Vent pipe
G I Air Vent pipe
✅ General Specifications:
| Parameter | Details |
|---|---|
| Material | Galvanized Iron (GI), as per IS 1239 / IS 3589 standard |
| Pipe Diameter | 15 mm to 150 mm (½" to 6") or as per project requirement |
| Pipe Length | 1 meter to 6 meters (customizable) |
| Pipe Thickness | Class A, B, or C (light, medium, heavy duty GI pipe) |
| End Connection | Plain end / Threaded / Flanged / Welded |
| Surface Finish | Hot-dip galvanized coating (zinc coated for rust protection) |
| Coating Thickness | 80 to 120 microns (as per IS 4736) |
| Mounting | Vertical installation (often with a rain cap or mesh cover on top) |
| Accessories | Air vent cap, mesh, elbow, reducer, flange (if needed) |
| Working Pressure | Suitable for low to medium pressure systems (up to 10 kg/cm² approx.) |
| Application Areas | Water supply lines, overhead tanks, sewerage systems, plumbing systems |
Yes I'm Interested
📌 Functions of GI Air Vent Pipe:
-
Releases trapped air in pipelines or tanks
-
Prevents negative pressure (vacuum)
-
Allows proper flow in gravity-based systems
-
Reduces pipe corrosion and water hammer effects
🛠️ Optional Add-ons:
-
Vent Cowl / Cowl Cap – Prevents debris entry
-
Non-return Valves / Air Release Valves – For advanced pressure systems
-
Wire Mesh Cover – To prevent insects or rodents from entering
